PM810MD RUGGED 2-IN-1 MEDICAL TABLET 10.1″

Slim, Anti-microbial, UL60601-1 Certified Tablet for Efficient Operations

The PM810MD Rugged 2-in-1 Medical Tablet features the integration of a brilliant 10.1″ capacitive touch screen and a high performance, energy-efficient Intel® Core™ i series processor within a slim, lightweight, durable package. With built-in front and back cameras, Wi-Fi, Bluetooth as well as optional data capture modules, this medical tablet offers health professionals an effective tool to monitor, record and retrieve patient information.

Features

  • 10.1″ Full-HD capacitive touch screen, 1000 nits, digital pen support
  • Intel® i processor
  • Microsoft® 10 IoT Enterprise or Ubuntu operating system
  • NIST compliant BIOS available
  • UL60601-1 certified with anti-microbial enclosure
  • Docking keyboard option for 2-in-1 (tablet/ laptop) applications
  • Hot swappable battery pack
  • IP65-rated for water and dust resistance
  • MIL-STD-810G for shock and vibration protection
  • Built-in front and back cameras
  • Built-in smart card/CAC reader



Major Options

  • Barcode scanner
  • NFC/RFID reader
  • 4G LTE/AWS

Specifications

CPUIntel® Core™ i5-8250U, Quad-Core, 1.6GHz (up to 3.4GHz)
Intel® Core™ i7-8550U, Quad-Core, 1.8GHz (up to 4.0GHz)
RAM8GB to 16GB
Storage256GB to 512GB Flash
Operating SystemMicrosoft® 10 IoT Enterprise or Ubuntu
NIST ComplianceNIST compliant BIOS available
Display10.1” LED-backlight, high-brightness (1000 nits) screen with capacitive touch, outdoor viewable
Display Resolution1920 x 1200
Network InterfaceWi-Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.2 LE
Control Switch and Buttons1 power button, 2 brightness control buttons, 5 programmable buttons
SpeakerBuilt-in speaker
CameraFull-HD front camera and 8 megapixel back camera
USB PortUSB 3.0 x 1, USB Type C x 1 (data transmitting and charging)
Headset Jack1 (3.5mm)
Smart Card/CAC ReaderFull-slot, reads ISO 7816 T=0, T=1; 1.8/3/5V smart card
EthernetEthernet 10/ 100/ 1000MB Base-T LAN
AC/DC AdapterInput: 100-240V AC; Output: 20V DC, 3A
Battery PackHot swappable battery, 11.4V, 5400mAh
EnclosureABS + PC plastics and magnesium-aluminum alloy; anti-microbial enclosure
Dimensions (H x W x D)7.8 x 11 x 0.86 in/ 198 x 280 x 21.9 mm
Weight3.1 lbs/ 1.4 kg
DurabilityIP65 and MIL-STD-810G certified
RegulatoryFCC Class B, UL60601-1, CE, RoHS compliant
TemperatureOperation: -10°C to 60°C (-14°F to 140°F), optional -30°C to 60°C (-22°F to 140°F)
Storage: -55°C to 70°C (-67°F to 158°F)
Humidity0% – 90% non-condensing
BARCODE SCANNER2D barcode scanner; reads 1D also
NFC/RFID READERHF 13.56MHz, ISO standard 15693, 14443A(B) & 18000-3 mode-1
MOBILE BROADBAND4G LTE/AWS

Accessories

keybrf
Docking Keyboard

Ports for Power, COM, LAN, HDMI output and USB; designed to connect to the 301MD rugged tablets, instantly pairs, ideal for 2-in-1 applications.

Battery Gang Charger white
Battery Gang Charger

Simultaneously charge 6 external batteries.

pen
Digital Pen

Dimension: 9.7mm x 140.7mm; Weight: <25g. Battery: 1 AAAA.

cradle
Desktop Charging Cradle

Docking support with ports for Power, USB, HDMI output and Ethernet.

cvav
Tablet Mount Cradle

Offers Tablet storage and security with power, HDMI-out, COM, Ethernet pass-through, and USB ports; power supply is not included.

btrrya
Battery Charger Kit with AC Adapter and Power cord

Recharges battery pack “offline” without affecting tablet use.

acdc
AC/DC Power Adapter with Power Cord

Facilitates Tablet operation or battery recharge. USB Type-C connector.

btryr
Battery Pack

Hot swappable, 60W.

slot
3-Slot Battery Holster

Supplies powers to the system and peripherals (e.g., Zebra mobile printer and Welch Allyn vital sign monitor).
