PM810XL RUGGED 2-IN-1 TABLET 11.6”

Slim, Rugged, Multi-functional Wireless Computing

The PM810XL Rugged Tablet features the integration of a high brightness 11.6” capacitive touch screen and a high performance, energy-efficient 8th generation Intel® Core™ i processor within a slim, lightweight, durable package. With a built-in smart card/CAC reader, Wi-Fi and Bluetooth as well as options for front/ back cameras, barcode scanner, long range Bluetooth and GNSS, this rugged tablet offers seamless information capture and transmission for improved workflow. Rated IP65, MIL-STD-810G and HERO certified with wide temperature range, the PM810XL Rugged Tablet provides reliable operation in harsh, mission-critical environments.

Features

  • 11.6″ Full-HD capacitive touch screen, 1000 nits, digital pen support
  • Intel® i5/i7 processor
  • Microsoft® 10 IoT Enterprise operating system
  • NIST compliant BIOS available
  • High capacity, hot-swappable battery pack
  • Built-in smart card/CAC reader
  • IP65 rated, MIL-STD-810G and MIL-STD-461F certified
  • HERO (Hazard of Electromagnetic Radiation to Ordnance) certified
  • Detachable keyboard option for 2-in-1 applications



Major Options

  • Front and back cameras
  • Intel® RealSense™ back camera
  • 2D barcode scanner; reads 1D also
  • UHF RFID reader
  • Long range Bluetooth
  • U-blox M8 GNSS module
  • 4G LTE/AWS

Specifications

CPUIntel® Core™ i5-8250U, Quad-Core, 1.6GHz (up to 3.4GHz)
Intel® Core™ i7-8550U, Quad-Core, 1.8GHz (up to 4.0GHz)
RAM8GB to 32GB
Storage256GB to 2TB Flash
Operating SystemMicrosoft® 10 IoT Enterprise
NIST ComplianceNIST compliant BIOS available
Display11.6” LED-backlight, high-brightness (1000 nits) screen with capacitive touch, outdoor viewable
Display Resolution1920 x 1080
Network InterfaceWi-Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.2 LE
Control Switch and Buttons1 power button, 2 brightness control buttons, 5 programmable buttons
SpeakerBuilt-in speaker
USB PortUSB 2.0 x 1, USB 3.0 x 1, USB Type C x 1 (data transmitting and charging)
Headset Jack1
Ethernet1 RJ45 connector for Ethernet
Smart Card/CAC ReaderFull-slot, reads ISO 7816 T=0, T=1; 1.8/3/5V smart card
AC/DC AdapterInput: 100 – 240V AC; Output: 20V DC, 3.25A
Battery PackHot swappable battery, 11.4V, 5400mAh
Hot swappable battery, 11.4V, 8000mAh (optional)
EnclosureABS + PC plastics and magnesium-aluminum alloy
Dimensions (H x W x D)8.3 x 12.4 x 0.86 in/ 212 x 316 x 21.9 mm
Weight3.5 lbs/ 1.6 kg
DurabilityIP65, MIL-STD-810G and MIL-STD-461F certified
Hazard of Electromagnetic Radiation to Ordnance (HERO) TestingYes
RegulatoryFCC Class B, CE, RoHS compliant
TemperatureOperation: -10°C to 60°C (-14°F to 140°F), optional -30°C to 60°C (-22°F to 140°F)
Storage: -55°C to 70°C (-67°F to 158°F)
Humidity0% – 90% non-condensing
BARCODE SCANNER2D barcode scanner; reads 1D also
CAMERA2 megapixel front camera, and 8 megapixel back camera with auto focus, white balance, gain control, and exposure control; or, Intel® RealSense™ Depth back camera, supports distance capture for 3D scanning, environment sensing, and background segmentation applications
UHF RFID READER865MHz – 928MHz, EPCglobal Class 1 Gen 2/ ISO 18000-6C. 30 feet (9.14m) in read distance
LONG RANGE BLUETOOTHClass 1 Bluetooth (1000 ft)
GNSS MODULEU-blox M8 GNSS module with concurrent reception of GPS and GLONASS, industry leading -167dBm navigation sensitivity
MOBILE BROADBAND4G LTE/AWS

Accessories

docking
Docking Keyboard

With ports for Power, LAN, HDMI output and USB; designed to connect to the PM810XL rugged tablets, instantly pairs, ideal for 2-in-1 applications.

btry
Battery Gang Charger

Simultaneously charge 6 external batteries.

pen
Digital Pen

Dimension: 9.7mm x 140.7mm; Weight: <25g. Battery: 1 AAAA.

PD316 RUGGED TABLET 10.1″
Desktop Charging Cradle

Docking support with ports for Power, USB, HDMI outputs and Ethernet.

PD316 RUGGED TABLET 10.1″
Tablet Mount Cradle

Offers Tablet storage and security with power, HDMI-out, COM, Ethernet pass-through, and USB ports. Power supply is not included.

btrrya
Battery Charger Kit with AC Adapter and Power cord

Recharges battery pack “offline” without affecting tablet use.

keyboard
Keyboard Mounting Kit for Vehicle/Wall Mount Cradle

Includes ACC-008-50T and PMT packaging. Designed to be attached with the Wall/Vehicle Mount Cradle. The Keyboard Mounting Kit can be folded up when not in use.

case
Carrying Case

Open-to-use design with foldable tabletop stand. Made of 1680 denier nylon fiber with water-repellent coating.

vs
Carrying Case and Portfolio

Added protection and secure portability to the Rugged Tablets from scratches, bumps, and drops.

protector
Screen Protector

Advanced coating technologies, provides anti‐reflection and high transparency to keep bright and crisp visuals while guarding against scratches and physical damage.

acdc
AC/DC Power Adapter with Power Cord

Facilitates Tablet operation or battery recharge. USB Type-C connector.

strap
Shoulder Strap for Tablets

Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.

auto
Automobile Power Adapter by LIND

Output voltage 65W/ 19V. Input: 11-16V DC.

handstrap
X-Handstrap

Designed to securely hold the Tablet. Made of soft plastic, easy to clean. For left- or right-handed users.
